Prices 986310123000004 Ephy Mess Italy

BRAND	Ephy Mess
Product	986310123000004
Description	thermometer
Internal code	PRT4957287
Custom code	90259000
Technical specification	PR-SPA-EX-LTH iBExu 14 ATEX 1291 X, II 2G Ex eb IIC T6... T3 Gb II 2G Ex ia IIC T6... T3 Gb please_note_manual_point_10 screw-in resistance thermometer, LT, 3Pt100, 4-wire circuit Class B ±0.3°C at 0°C in accordance with DIN EN 60751 connection head, aluminum Size: ø6x444mm/ Cover: yes Sealed: yes Cable outlet: NPT 1/2" cable screw VSB: solid, stainless steel, NPT 1/2"/SW 22 Supply line: 3x hose [4xAWG 20/7-Cu-silver-plated/PTFE/FEP, KL=15000mm, length tolerance: +152/-0, Ø: 4.1mm] GY (3x (RD/RD/WH/WH)), Measurement range: -20°C... +180°C Ambient temperature: -20°C... +75°C Insulation resistance: ≥ 100 MΩ/100 VDC Dielectric strength: 0.5 kV AC. 50 Hz/1min. Dielectric strength: element to element: 0.5 kV AC. 50 Hz/1min. Installation length to bottom edge of screw connection: 444 ±1.6mm Differences from EMT688-234 Rev.A: Temperature measurement range: -20°C to +180°C Connection head material: aluminum

You can find the current prices belongs to Ephy Mess - 986310123000004 coded thermometer product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. Our company supply 986310123000004 referenced product fastest and securest on your request. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
