| BRAND | Schniewindt |
| Product | 90N/G2-60-0,98-690 / PAT-052621-051349 |
| Description | cartridge radiator |
| Internal code | PRT4979527 |
| Weight | 4 |
| Custom code | 85161080 |
| Technical specification | Type 90N/G Vibration-resistant design Heating element type RHK ------------ Radiator technical part ------------ Supply voltage [V] 690.00 Total output [kW] 0.980 Standard power tolerance (+5/-10%) Tol. based on heat output Upper heat tolerance (%) 5 Lower heat tolerance (%) -10 Star connection Protection class IP 65 Installation position horizontal Installation length [mm] 600.0 Upper floor installation length [mm] 10 Lower floor installation length [mm] -10 Unheated length [mm] 50 ------------ Heater insert mounting ------------ Type of fastening screw G 2 - SW 70 screw connection Bolting material steel ------------ cartridge tube ------------ Diameter [mm] Ø 52 mm Material steel Surface load [W/cm²] 1.09 ------------ Ceramics Ohne/not relevant tubular heater ------------ number 3 Diameter [mm] Ø 11.5 mm Surface load [W/cm²] 0.86 Pipe material 1.4828 Type of closure Giso-G ------------ connection hood ------------ Hood diameter 61 x 68 mm Hood material galvanised steel M20 cable connector Cable connector material plastic Cable fitting position Radial accessory ------------ Seal, Nut With Seal Aramid seal material (WS 3820, novapress UNIVERSAL, Aremi,...) ------------ Old article number 201R916634907 operating conditions: Medium gear oil Max. operating temperature [°C] 80 Ambient temperature min. [°C] -40 Ambient temperature max. [°C] 40 Maximum allowable pressure (hp) [barg] 0.5 Operating pressure [barg] 0.50 Pressure equipment directive Compliance with Directive Ohne, < 0.5 bar (g) |
Where can I buy 90N/G2-60-0,98-690 / PAT-052621-051349 by Schniewindt in Italy?
You can purchase 90N/G2-60-0,98-690 / PAT-052621-051349 by Schniewindt from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the 90N/G2-60-0,98-690 / PAT-052621-051349?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Schniewindt in Italy?
While we are not the official distributor or seller of Schniewindt in Italy, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.
How can I access 90N/G2-60-0,98-690 / PAT-052621-051349 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 90N/G2-60-0,98-690 / PAT-052621-051349 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 90N/G2-60-0,98-690 / PAT-052621-051349?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
