Prices DFV 50 DD-B5.0 ZBA 100 AL 4-B050 Demag Italy

BRAND	Demag
Product	DFV 50 DD-B5.0 ZBA 100 AL 4-B050
Description	Spur gear brake motor
Internal code	PRT5075241
Weight	56
Technical specification	DEMAG - Spur gear brake motor Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: DFV50DD-B5.0-40-0/33,1 design key - ZBA 100 AL 4-B050 Output speed 42.7 rpm Motor speed 1415 rpm Output 2,200 kW Operating time 60% Motor protection class IP 54 Ambient temperature Gear motor -10... +50 °C Installation height ≤ 1,000 m Translation 33.10 Terminal box layer at the top, 0 Horizontal motor installation position Electrical data: Supply voltage D/Y 220-230/380-400 V Line frequency 50 Hz Current D/Y 8.80/5.10 A Brake technical data: Braking torque 33.0 Nm Voltage 104 V DC Current 0.29 A GE 230V AC brake rectifier equipment: 1 KTY84-130 temperature sensor for insulation according to thermal class F with phase insulation for inverter operation Built-in fan 400 V 50/60 Hz, protection class IP 54 Light fan disc GE brake rectifier noise-reduced version flange design Gearbox with vent valve Direct input Execution in accordance with order number: 881801 from 2011 color scheme: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive

Demag - DFV 50 DD-B5.0 ZBA 100 AL 4-B050 referenced Spur gear brake motor product produced by high technology.
DFV 50 DD-B5.0 ZBA 100 AL 4-B050 became irreplaceable of foundations. DFV 50 DD-B5.0 ZBA 100 AL 4-B050 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Make an offer to us for DFV 50 DD-B5.0 ZBA 100 AL 4-B050 please contact us.

Where can I buy DFV 50 DD-B5.0 ZBA 100 AL 4-B050 by Demag in Italy?

You can purchase DFV 50 DD-B5.0 ZBA 100 AL 4-B050 by Demag from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the DFV 50 DD-B5.0 ZBA 100 AL 4-B050?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Demag in Italy?

While we are not the official distributor or seller of Demag in Italy, we source our products from reliable channels and offer you original Demag equipment at competitive prices.

How can I access DFV 50 DD-B5.0 ZBA 100 AL 4-B050 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DFV 50 DD-B5.0 ZBA 100 AL 4-B050 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DFV 50 DD-B5.0 ZBA 100 AL 4-B050?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
