Prices 23614K-800-ANSI-2” Weka Italy

BRAND	Weka
Product	23614K-800-ANSI-2”
Description	magnetic level indicator
Internal code	PRT5023894
Weight	25
Custom code	902610
Technical specification	Standard Line 6 series Material bypass pipe 316/316L; 53x1.5m cap on top, blind flange on bottom, with G3/8" drain hole including plug Display rail: 38602E 316/PC for Tmax. +150°C, IP65 Red-silver aluminum plates Medium: oil/water, density 0.77 g/cm 3 Operating data Tmax. 90°C, Pmax. 4bar Connector spacing: L=800mm laterally. Connections: ANSI B16.5 2"/CLASS150/RF SF flanges Extras (included): - Manufacture of the VLI according to ATEX - Transmitter type 29710-R-NI-010-05-800 intrinsically safe Ex I, IP 68 for combination with HART module 4... 20mA current output Measurement length “M el. = 800mm, resolution 5mm Tmax 150°C - HART converter module 37384 intrinsically safe Ex i in the IP65 terminal box - 46307-02 mounting plate for HART module - Functional test (including hydrostatic pressure test) confirmed with factory certificate EN 10204:2004-2 .2

Weka - 23614K-800-ANSI-2” referenced magnetic level indicator product produced by high technology.
23614K-800-ANSI-2” is the result of a far more developed technology compared to similar regular products. We are one of the few companies which can present an offer for this product. Our company can make an offer even if we do not distributor of Italy. We present you the most competative price and delivery time on 23614K-800-ANSI-2” referenced product.

Where can I buy 23614K-800-ANSI-2” by Weka in Italy?

You can purchase 23614K-800-ANSI-2” by Weka from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 23614K-800-ANSI-2”?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Weka in Italy?

While we are not the official distributor or seller of Weka in Italy, we source our products from reliable channels and offer you original Weka equipment at competitive prices.

How can I access 23614K-800-ANSI-2” catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 23614K-800-ANSI-2” on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 23614K-800-ANSI-2”?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
