| BRAND | Dietz-Motoren |
| Product | 224235 , DN10Q FD71/25/2Q IP54-KST-M |
| Description | Drehstrom-Niederdruck-Radialventilator |
| Internal code | PRT2919313 |
| Weight | 5.5 |
| Technical specification | Spare for DN 10, device nr. 5163100 Type DN 10 Rated output: 0,11 // 0,19 kW Rated voltage: 200-240 / 346-420 / 200-277 / 346-480 V Rated frequency: 50 // 60 Hz Circuit: Delta / Star / Delta / Star Rated rotational speed: 2880 // 3300 rpm Thermal Class: 155 (F) Winding protection: without Motor protection: IP54 Max. Flow rate: 8 // 9.5 m3 / min Max. Total pressure increase: 300 // 430 Pa Paint Motor: Ral 7004 signal gray Painting Fan: Ral 7004 signal gray Terminal box material: plastic Screw-in thread: 1 x M16x 1.5 Cable gland: without Without protective grille Compliant with ErP Factory standard 040007100 Design and terminal box: LG 270-1A Drawing nr. Z2371602400 |
Where can I buy 224235 , DN10Q FD71/25/2Q IP54-KST-M by Dietz-Motoren in Italy?
You can purchase 224235 , DN10Q FD71/25/2Q IP54-KST-M by Dietz-Motoren from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the 224235 , DN10Q FD71/25/2Q IP54-KST-M ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Dietz-Motoren in Italy?
While we are not the official distributor or seller of Dietz-Motoren in Italy, we source our products from reliable channels and offer you original Dietz-Motoren equipment at competitive prices.
How can I access 224235 , DN10Q FD71/25/2Q IP54-KST-M catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 224235 , DN10Q FD71/25/2Q IP54-KST-M on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 224235 , DN10Q FD71/25/2Q IP54-KST-M ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
