Prices 1301A /VX5 1004 B2 - EUROCHAIN Verlinde Italy

BRAND	Verlinde
Product	1301A /VX5 1004 B2 - EUROCHAIN
Internal code	PRT5168240
Weight	37
Technical specification	Rated capacity1000 kg VX5 1004 B2 - EUROCHAIN 1301A Height of lift 6 m Load chain DAT chain Reeving 02 Hoisting speed 4 / 1 m/min Hoisting motor power 0.72 KW Hoisting motor - nominal current 2.4/1.6 A Hoisting motor - starting current 7.2/2.35 A Hoist duty group M5 Hoist duty class EN 14492-2 A5 / Dh2 Hoist suspension Bracket long Trolley type None Main voltage 400 V Phase count 3 Phases Frequency 50 Hz Control voltage 48 V Pendant cable length 5.5 m Chain bag Yes Protection class IP55 Mechanical overload device Friction torque limiter Standard temperature range -20°C to +40°C with rated load and speed (ED 60%, 300 start/hr) Hoisting limit switch Electrical upper & lower limit switch (2 steps) Paint 5 years guaranteed RAL 7021 Standard maximum humidity 90 % Control pendant Remco 2 button pendant with emergency stop Approx. hoist weight including options 37 kg C-dimension (headroom) 489 mm Overheating protection for hoisting motor Included Hoist Options: Chain lubrication Grease Chain bag Standard Documents: Number of documents in package 1 Language of documents English (EN) Document delivery Documents to be shipped with the material

You can find the current prices belongs to Verlinde - 1301A /VX5 1004 B2 - EUROCHAIN coded product. You can ask all the codes and references except 1301A /VX5 1004 B2 - EUROCHAIN too. 1301A /VX5 1004 B2 - EUROCHAIN referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Contact us if you are looking for alternative price of 1301A /VX5 1004 B2 - EUROCHAIN .

Where can I buy 1301A /VX5 1004 B2 - EUROCHAIN by Verlinde in Italy?

You can purchase 1301A /VX5 1004 B2 - EUROCHAIN by Verlinde from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 1301A /VX5 1004 B2 - EUROCHAIN?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Verlinde in Italy?

While we are not the official distributor or seller of Verlinde in Italy, we source our products from reliable channels and offer you original Verlinde equipment at competitive prices.

How can I access 1301A /VX5 1004 B2 - EUROCHAIN catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 1301A /VX5 1004 B2 - EUROCHAIN on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 1301A /VX5 1004 B2 - EUROCHAIN?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
