Prices 000 163 - ATMOS V4-KR Var.0102 Baratti Italy

BRAND	Baratti
Product	000 163 - ATMOS V4-KR Var.0102
Internal code	PRT4856168
Custom code	84141025
Technical specification	ATMOS V4-KR Var.0102 rotary blower vacuum - absolutely oil-free and wear-free compression - Labyrinth sealing for the compressor chamber with relief hole - air-cooled, V-belt drive with belt protection - two-stage exhaust muffler - including vacuum relief valve - including suction side fine paper filter - including glycerin-filled spring pressure gauge D = 63 mm (-1 to 0 bar) Technical data in general: Suction volume: 80 to 640m3/h (15 to 75Hz) Vacuum (continuous): 300mbar abs. Ultimate vacuum (intermittent): 100mbar abs. Fan speed: 800 to 4500min -1 (15 to 75Hz) Vacuum relief valve size: 1 Fine filter suction side connection thread: R 3 “” Outer diameter of exhaust pipe: 76.1 mm Noise level (depending on speed/pressure) approx.: 76 dB (A) dB (A) (after free-field measurement DIN 45635) For dimensions, see measurement sheet no.: 900088AA Technical data for your application: Suction volume: 440 m³/h max. negative pressure: -400 mbar Fan speed: 2935 rpm Motor: 11 kW, 3 x 400 V, 50 Hz, 2950 rpm, B3 KKL, IE 3 OIL FILLING: Castrol Alphasyn EP220 PAINTING: RAL 7011 compressor, 4007 motor, 9005 frame Anbantoile

You can find the current prices belongs to Baratti - 000 163 - ATMOS V4-KR Var.0102 coded product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. Our company can make an offer even if we do not distributor of Italy. We present you the most competative price and delivery time on 000 163 - ATMOS V4-KR Var.0102 referenced product.
