Prices 000 163 - ATMOS V4-KR Var.0102 Baratti Italy

BRAND	Baratti
Product	000 163 - ATMOS V4-KR Var.0102
Internal code	PRT4856168
Weight	450
Custom code	84141025
Technical specification	ATMOS V4-KR Var.0102 rotary blower vacuum - absolutely oil-free and wear-free compression - Labyrinth sealing for the compressor chamber with relief hole - air-cooled, V-belt drive with belt protection - two-stage exhaust muffler - including vacuum relief valve - including suction side fine paper filter - including glycerin-filled spring pressure gauge D = 63 mm (-1 to 0 bar) Technical data in general: Suction volume: 80 to 640m3/h (15 to 75Hz) Vacuum (continuous): 300mbar abs. Ultimate vacuum (intermittent): 100mbar abs. Fan speed: 800 to 4500min -1 (15 to 75Hz) Vacuum relief valve size: 1 Fine filter suction side connection thread: R 3 “” Outer diameter of exhaust pipe: 76.1 mm Noise level (depending on speed/pressure) approx.: 76 dB (A) dB (A) (after free-field measurement DIN 45635) For dimensions, see measurement sheet no.: 900088AA Technical data for your application: Suction volume: 440 m³/h max. negative pressure: -400 mbar Fan speed: 2935 rpm Motor: 11 kW, 3 x 400 V, 50 Hz, 2950 rpm, B3 KKL, IE 3 OIL FILLING: Castrol Alphasyn EP220 PAINTING: RAL 7011 compressor, 4007 motor, 9005 frame Anbantoile

You can find the current prices belongs to Baratti - 000 163 - ATMOS V4-KR Var.0102 coded product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. Our company can make an offer even if we do not distributor of Italy. We present you the most competative price and delivery time on 000 163 - ATMOS V4-KR Var.0102 referenced product.

Where can I buy 000 163 - ATMOS V4-KR Var.0102 by Baratti in Italy?

You can purchase 000 163 - ATMOS V4-KR Var.0102 by Baratti from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 000 163 - ATMOS V4-KR Var.0102?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Baratti in Italy?

While we are not the official distributor or seller of Baratti in Italy, we source our products from reliable channels and offer you original Baratti equipment at competitive prices.

How can I access 000 163 - ATMOS V4-KR Var.0102 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 000 163 - ATMOS V4-KR Var.0102 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 000 163 - ATMOS V4-KR Var.0102?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
